FLM 55GX Genesis Ball Head (55mm) with 15° Stop Function & QBL-60 Quick Release Lever Clamp
Key Features
FLM 55GX Genesis Ball Head with 15" Stop Function
- Load Capacity: 40 kg
- Friction Control
- Indépendant Pan Lock Knob
- Reversible 1/4"-20 to 3/8"-16 Mount Stud
- Weight: 330 g
- 10-Year Manufacturer Warranty
FLM QBL-60 Quick Release Lever Clamp
- Arca-Type Quick Release Clamp
- Locking Lever
- 2 x Bubble Level
- Adjustable Plate Size capacity
- Load Capacity 40 kg
- Aluminum Construction
- 10-Year Manufacturer Warranty
The FLM 55GX Genesis Ball Head & 15" Stop Function is a light yet strong ball head with a simplified but effective friction lever, a low-profile design, an anodised satin-surface ball.
Part of the GX series, this ball head will impress with its compact size and remarkable strength. Made for smaller tripods such as the CP30 and CP34 series, the 55GX can easily accept any QR clamp.
Perfect for cameras where carrying weight is important. The 47GX uses friction and pan control and it has the 15" Stop function. Includes a reversible 1/4" - 3/8" mounting screw.
- Recommended clamps: SRB-60, QLB-60.
- Recommended tripods: CP30, CP34
- Recommended camera type: DSLR (full-frame and crop sensor), Medium Format (film & digital)
- Recommended lenses: 150-600mm, 400mm
The QLB-60 Quick Release Lever Clamp by FLM is an open channel Arca-style lever clamp that allows for different size quick release plates. It has a safety pin so that plates will not slide out of the clamp when it is loose. Built-in bubble levels helps align your camera vertically and horizontally. The easiest and quickest solution for locking camera plates securely in place with a new lever-actuated system. One jaw is adjustable to accommodate various Arca plate sizes, then the lever can be opened and closed quickly. A locking pin ensures that the QR plate cannot slip out of the base when opened. This base is additionally equipped with a bubble level to facilitate horizontal alignment of the camera. Arca-compatible and adjustable to various Arca plates.
Specification
FLM 55GX Genesis Ball Head with 15" Stop Function
| Head Type | Ball Head |
| Base Mount | 3/8"-16 Thread |
| Camera Mounting Screw | 3/8"-16 Male |
| Load Capacity | 88.2 lbs / 40kg |
| Ball Diameter | 2.17" / 55mm |
| Weight | 0.73 lbs / 330g |
| Height | 3.1" / 80mm |
| Base Diameter | 2.28" / 58mm |
FLM QBL-60 Quick Release Lever Clamp
| Base Mount Thread | 3/8"-16 Female |
| Plate Locking Method | Lever |
| Quick Release Plate Type | Arca-Type |
| Bubble Level | Yes |
| Load Capacity | 40 kg |
| Material | Aluminum |
| Length | 107 mm |
| Width | 70 mm |
| Height | 15 mm |
| Weight | 120 g |
