FLM 47GX Genesis inc QLB-50 II Ball Head 47mm with QLB-50 II Lever Clamp
Development by DDSHOPAPPS
FLM 47GX Genesis Ball Head (47mm) with 15° Stop Function & QBL-50 II Quick Release Lever Clamp
Key Features
FLM 47GX Genesis Ball Head with 15" Stop Function
- Load Capacity: 25 kg
- Friction Control
- Indépendant Pan Lock Knob
- Reversible 1/4"-20 to 3/8"-16 Mount Stud
- Weight: 240 g
- 10-Year Manufacturer Warranty
FLM QBL-50 II Quick Release Lever Clamp
- Length: 3"
- Arca-Type Compatible
- Safety Pin
- Lever Lock
- 3/8"-16 Tripod Mounting Thread
- 10-Year Manufacturer Warranty
The FLM 47GX Genesis Ball Head & 15" Stop Function is a light yet strong ball head with a simplified but effective friction lever, a low-profile design, an anodised satin-surface ball.
Part of the GX series, this ball head will impress with its compact size and remarkable strength. Made for smaller tripods such as the CP22 and CP26 series, the 47GX can easily accept any QR clamp.
Perfect for cameras where carrying weight is important. The 47GX uses friction and pan control and it has the 15" Stop function. Includes a reversible 1/4" - 3/8" mounting screw.
- Recommended clamps: SRB-40, QLB-50.
- Recommended tripods: CP22, CP26
- Recommended camera type: P&S, M43, APS-C, DSLR (full-frame and crop sensor)
- Recommended lenses: 70-200mm, 100-400mm
The FLM QBL-50 II Quick Release Lever Clamp is the easiest and quickest solution for locking camera plates securely in place with a new lever-actuated system. One jaw is adjustable to accommodate various Arca plate sizes, then the lever can be opened and closed quickly. A locking pin ensures that the QR plate cannot slip out of the base when opened. This base is additionally equipped with a bubble level to facilitate horizontal alignment of the camera. Arca-compatible and adjustable to various Arca plates.
Specification
FLM 47GX Genesis Ball Head with 15" Stop Function
| Head Type |
Ball Head |
|---|---|
| Base Mount |
3/8"-16 Thread |
| Camera Mounting Screw |
3/8"-16 Male |
| Load Capacity |
55.1 lb / 25 kg |
| Ball Diameter |
1.85" / 47mm |
| Weight |
0.53 lbs / 240g |
| Height |
2.83" / 72mm |
| Base Diameter |
1.85" / 47mm |
FLM QBL-50 II Quick Release Lever Clamp
| Quick Release Type |
Arca-Type, Lever |
|---|---|
| Tripod Mounting Thread |
3/8"-16 Female |
| Dimensions |
3"x2.25"x0.6" / x57x16 mm |
| Base Mount Thread | 3/8"-16 Female |
| Plate Locking Method | Lever |
| Quick Release Plate Type | Arca-Type |
| Bubble Level | Yes |
| Load Capacity | 25.0 kg |
| Material | Aluminum |
| Length | 94 mm |
| Width | 60 mm |
| Height | 15 mm |
| Weight | 86 g |
